Pickleball Court Dimensions: Size, Measurements and the Space You Need

The regulation 20 by 44 ft court, the kitchen, net height, line widths and how much yard a full court really takes, from the team that builds them on concrete.

Local Maricopa County Builder Licensed & Insured
Experienced Team 20+ Years Experience
Easy Financing Low Monthly Payments

Quick answer: A regulation pickleball court is 20 ft wide by 44 ft long for singles and doubles. The non-volley zone (the kitchen) runs 7 ft back from the net on each side, the net is 36 inches high at the sidelines and 34 inches at the center, and every line is 2 inches wide. USA Pickleball lists a minimum playing surface of 30 by 60 ft and recommends 34 by 64 ft for new courts. Size is one part of the picture; our pickleball court guide also covers cost, surface and how a court is built.

Dink Pro Courts builds backyard courts on concrete across the Phoenix area. Our team has 20+ years experience as a commercial and residential builder with Tyco Construction, our sister company. Licensed & Insured. This guide covers every measurement on the court, how much space to plan around it, and how those numbers translate to a real yard. If you are fitting a court into a home lot, see our backyard pickleball court dimensions page.

Pickleball Court Dimensions at a Glance

These are the core numbers from the USA Pickleball rulebook. All court measurements are taken to the outside edge of the perimeter and kitchen lines.

FeatureMeasurementNotes
Court (singles and doubles)20 ft wide by 44 ft long880 sq ft inside the outer lines
Non-volley zone (kitchen)7 ft deep by 20 ft wide, each sideLines bounding the kitchen are part of the kitchen
Service courts10 ft wide by 15 ft deep, four totalFrom the kitchen line to the baseline, split by the centerline
Line width2 inchesSame color, clearly contrasting with the surface
Net height36 in at the sidelines, 34 in at the centerThe small dip at the center is standard
Minimum playing surface30 ft by 60 ft1,800 sq ft, including space outside the lines
Recommended for new construction34 ft by 64 ft2,176 sq ft; the same size USA Pickleball lists for tournament play

In metric terms the court is 6.10 m by 13.41 m, the minimum surface is 9.14 m by 18.29 m, and the recommended new-construction surface is 10.36 m by 19.5 m.

How Big Is a Pickleball Court, Really?

The painted court is the smallest number you will see, and it is not the size of the slab. Players chase balls past the baseline and step wide of the sidelines on almost every point, so the playing surface has to extend beyond the lines.

Think of it in three layers:

For comparison, a two-car garage is roughly 20 by 20 ft, so the painted court alone is a little more than two garages laid end to end. The full recommended surface is closer to the footprint of a modest house.

Freshly poured slab being troweled inside block walls, Dink Pro Courts build in progress

Dink Pro Courts build in progress.

Every Line and Zone on the Court

Baselines and sidelines

The baselines run parallel to the net at each end of the court, 22 ft from the net. The sidelines run the full 44 ft length and mark the 20 ft width. Together they form the outer boundary.

The non-volley zone

The kitchen is the 7 by 20 ft area next to the net on each side. Players cannot volley while standing in it, and the lines around it count as part of the zone. Because so many rulings happen at this line, it has to be measured and painted precisely.

Centerline and service courts

The centerline runs from the kitchen line to the baseline on each side, splitting that area into the right (even) and left (odd) service courts. Each service court is 10 ft wide and 15 ft deep.

Net and posts

The net is 36 inches high at the sidelines and dips to 34 inches at the center. Net posts sit outside the sidelines, and on a permanent court we set the post sleeves in the concrete before the pour so the posts stand plumb and can come out when you want open space.

Want more on striping and line colors? See our guides to pickleball court lines and pickleball court colors.

Planning the Space in an Arizona Backyard

Fitting a court is about more than the rectangle. A few things decide whether a full court works in your yard:

Formed slab with vapor barrier and post-tension cables before the pour, Dink Pro Courts build in progress

Dink Pro Courts build in progress.

For a deeper look at backyard layouts, read our guide to court dimensions and space planning for Arizona yards or sketch your own in the court designer. To plan your own yard step by step, use our pickleball court layout guide, with a yard-measuring how-to and a layout checklist.

When a Full Court Will Not Fit

Not every lot has room for a 34 by 64 ft surface. A smaller court still gives you real games at home:

OptionCourtSlabGood for
Full pickleball court20 by 44 ft regulation linesSized to your yard, up to 34 by 64 ftSingles and doubles, regular play
Mini 1v1 Game Center12 by 26 ft20 by 36 ftSmaller yards; pickleball, basketball, shuffleboard and badminton
Mini Doubles Game Center20 by 35 ft26 by 45 ftDoubles-style play where a full court will not fit

See the Mini Pickleball Court Game Center and the mini pickleball court dimensions guide for layouts.

What a Court Costs

OptionPriceWhat is included
Full pickleball court$29,000*Concrete slab, acrylic surface, regulation lines, basic net and 4 paddles
Mini 1v1 Game Center$16,999*12 by 26 ft court on a 20 by 36 ft slab; four games
Mini Doubles Game Center$23,999*20 by 35 ft court on a 26 by 45 ft slab; four games
Financing$598/mo for 60 months, with excellent credit*Third-party lenders; subject to credit approval

* Courts start at $29,000 for a 54 ft x 28 ft court, with a basic net and 4 paddles included. Financing is $598/mo for 60 months with excellent credit. Site access, grading, drainage, fence height, lighting and the options you pick change the final price. See the pickleball court construction cost guide and our financing options.

Estimated rates and terms are not binding and are subject to change. Your actual APR depends on credit score, amount financed and credit history; only borrowers with excellent credit qualify for the lowest rates. All financing is subject to credit review and approval by lending partners.

How We Lay Out and Build Your Court

  1. Site visit and layout. We measure the yard, check slope and access, and mark the court and the playing surface around it.
  2. Grading and forms. The subgrade is shaped and compacted, then forms, a vapor barrier and post-tension cables go in, with net post sleeves set in place.
  3. Concrete pour and cure. As a typical range, not a promise: we can usually be pouring concrete within a week, then the slab cures 21 to 28 days depending on weather before we paint.
  4. Surface and lines. Acrylic color coats go down, then the 2 inch lines are measured to the outside edges and painted.
  5. Net and extras. The net goes up, plus any fence or lights in the plan.
Overhead view of a freshly poured backyard slab, Dink Pro Courts build in progress

Dink Pro Courts build in progress.

Read the full process on our pickleball court construction page.

Pickleball Court Dimensions Questions

A pickleball court is 20 ft wide and 44 ft long for both singles and doubles, per the USA Pickleball rulebook. Measurements run to the outside edge of the lines, and every line is 2 inches wide.

USA Pickleball lists a minimum playing surface of 30 ft by 60 ft and recommends 34 ft by 64 ft for new construction. Backyard courts are often sized between the painted court and those numbers, depending on the lot.

Each non-volley zone (the kitchen) is 7 ft deep from the net and runs the full 20 ft width of the court. The lines that bound the kitchen count as part of it.

The net hangs 36 inches high at the sidelines and 34 inches at the center.

Many Phoenix-area yards can fit a full court. If yours cannot, a mini court is an option. Send us your yard size and a few photos and we will tell you what fits before you commit.

Courts start at $29,000 for a 54 ft x 28 ft court, with a basic net and 4 paddles included. Financing is $598/mo for 60 months with excellent credit. Site access, grading, drainage, fencing and lighting change the final price.

The court is 20 by 44 ft (6.10 by 13.41 m). Each kitchen is 7 ft (2.13 m) deep, each service court is 10 by 15 ft, the net is 36 in at the sidelines and 34 in at the center, and lines are 2 in wide.

Yes. Singles and doubles are played on the same 20 by 44 ft court with the same lines. Only the serving and scoring rules change.

Yes. Every Dink Pro Courts court is built on a post-tension concrete slab, finished with an acrylic sport surface and regulation lines.
